J25 SEMI-HOLLOW Pelham Blue

We are in the process of finishing this J25 and have decided on the following specification but can change a few things at this stage like ageing, wraparound bridge type, pickguard.

Slightly smaller than our J35, the Case J25 has a 14" wide body width and is extremely well balanced on the strap. The guitar employs a traditional semi-hollow laminated maple construction with a light obeche centre block. The semi-hollow body creates a resonant, responsive tone, while the centre block maximises sustain and keeps feedback to a minimum. The neck is made from quarter sawn mahogany and has a beautiful dark rosewood fingerboard.

All hardware is high quality and includes an ABM compensated wraparound stopbar. Gotoh vintage tuners guarantee fine tuning and smooth operation. High quality CTS pots and Switchcraft components are used, together with a 50’s wiring scheme to minimise treble loss when rolling back the volume.

Hand wound Bare Knuckle ‘Nantucket’ P90s are chosen for their outstanding clarity and extended dynamic range. Even at low levels of gain, smooth harmonic feedback, full of overtones is possible, while clean sounds have depth and unmistakable vintage character.

S P E C I F I C A T I O N

BODY  Laminated maple, Obeche centre block. Depth 1.75'' (44mm)

NECK Mahogany, comfy C profile, quarter sawn, 21.5mm at 1st fret, 23.5 at 12th fret

SCALE LENGTH  24.75''

FINGERBOARD  12'' radius, dark rosewood, 57mm at 22nd fret

NUT  43mm Bone

BINDING  White - body and fingerboard

FRETS  22 Dunlop 6100 jumbo

MARKERS  12th fret mother of pearl ‘Wave’ inlay plus dots

TRUSS ROD  Adjustable double action

HEADSTOCK OVERLAY  Ebony

LOGO  Case logo inlayed in mother of pearl

HARDWARE  Nickel plated

BRIDGE  ABM compensated wraparound stopbar

TUNERS  Gotoh vintage keystone

CONTROLS  Master volume and master tone, Switchcraft 3-way selector switch

CAPACITORS  Sprague Orange drop .022

KNOBS  Black top hat reflector

FINISH  Nitrocellulose

COLOUR  Pelham Blue

PICKUPS  Bare Knuckle ’Nantucket’ P90 black soapbar set

BRIDGE  DC: 7.9 Magnet: Alnico V

NECK  DC: 7.1 Magnet: Alnico V

PICKUP RINGS  Black plastic

PICKGUARD Black laminated or Tortoise shell laminated

WEIGHT Estimated 6.3 lbs


STRINGS  D'Addario EXL110 10-46 regular light strings

CASE  Hiscox hard shell

£4,150

OPTIONAL EXTRAS

ABM fully adjustable wraparound stopbar + £60

Aged hardware, low lustre cellulose finish + £150

Aged hardware, high gloss or low lustre crazed cellulose finish + £300

2 x volumes, 2 x tones
